Description
Description – Steel Flange with weld neck connection
Material – 304/316 SS, Hastelloy, Carbon Steel
Thread Type – NPT/BSP/BSPT
Pressure Class – 150, 300, 400, 600, 900, 1500, 2500
Size Range – 1″ to 1/4″, 1″ to 1/2″, 1 1/2″ to 1/2″, 2″ to 1/2″, 3″ to 1/2″, 4″ to 1/2″, 1″ to 3/4″, 1 1/2″ to 3/4″, 2″ to 3/4″, 3″ to 3/4″, 4″ to 3/4″, 1 1/4″ to 1″, 1 1/2″ to 1″, 2″ to 1″, 2 1/2″ to 1″, 3″ to 1″, 4″ to 1″, 1 1/2″ to 1 1/4″, 2″ to 1 1/4″, 4″ to 1 1/4″, 2″ to 1 1/2″, 2 1/2″ to 1 1/2″, 3″ to 1 1/2″, 4″ to 1 1/2″, 2 1/2″ to 2″, 3″ to 2″, 4″ to 2″, 3″ to 2 1/2″, 4″ to 2 1/2″, 4″ to 3″, 6″ to 4″, 8″ to 6″
Application – Chemical Manufacturing, Food Equipment, Pharmaceutical, Petrochemical, Steel Manufacturing, Distilling, Food and Beverage, Pulp and Paper Processing, Power Generation, Marine, etc
NOTE : User to verify the compatibility
Also known as Pressure Class 150 flanges, these are designed for low-pressure pipe applications. Bolt two flat-surface flanges or two raised-surface flanges of the same size together with a gasket (sold separately) to create an access point within a line.
316 stainless steel flanges have excellent corrosion resistance.
Forged flanges have better strength than cast flanges. They are also called ANSI flanges.
Reducing flanges allow you to transition your system to a smaller pipe size; attach to a flange with a larger pipe size but with the same flange dimensions. ”
